TQC Micromotor
TQC Micromotor
| NOMINAL VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | AT STALL | ||||||
|---|---|---|---|---|---|---|---|---|---|
| SPEED (RPM) | CURRENT (A) | SPEED (RPM) | CURRENT (A) | EFFICIENCY (%) | TORQUE (g.cm) | OUTPUT (W) | TORQUE (g.cm) | CURRENT (A) | |
| 12 VDC | 23600 | 0.7 | 20532 | 4.73 | 64.1 | 172.6 | 36.35 | 1327.5 | 31.68 |
A: We produce Brushed DC Motors, Brushless DC Motors, Planetary Gearboxes, etc. You can check the detailed specifications in our catalog or contact us for more information.
A: Yes, we provide comprehensive customization for voltage, speed, torque, shaft size/shape, and can add specialized connectors or capacitors as required.
A: Please provide your specific requirements such as voltage, speed, torque, and dimensions or drawings. Our team will recommend the most suitable model for your application.
A: For in-stock items, it takes 5-10 days. Standard production takes 15-30 days, while customized orders are evaluated on a case-by-case basis.
A: We maintain a professional QC team and implement strict inspection protocols throughout the production process, from raw materials to the final finished products.
A: Our motors are fully compliant with international standards and hold CE and ROHS certifications.
